The Production Infrastructure Overview and Production Infrastructure Directories articles describe the environment that the scripts on this page operate within.
All of these scripts require Ruby to be set up; please see Setting Up a Ruby Development Environment.
Create Song Structure
The following script creates the subdirectory structure for a song. Any pre-existing files in the directory are moved to their appropriate subdirectories. A private GitHub repository is created for the song.
Use the A Streamlined Git Commit to ensure that only files that fit in Git are checked in.
Installation
-
Install dependencies:
Shell
$ gem install colorator
$ gem install mime-types -
Save the code as
song_createin a directory on thePATH, such as/usr/.local/ bin/ -
Make
song_createexecutable:
Shell$ sudo chmod a+x /usr/local/bin/song_create
Example Usage
This script can be called from any directory.
$ song_create $songs/test Creating a new song subdirectory structure in '/mnt/e/media/songs/test' /mnt/e/media/songs/test/daw /mnt/e/media/songs/test/dvrArchives /mnt/e/media/songs/test/inputs/image /mnt/e/media/songs/test/inputs/video /mnt/e/media/songs/test/outputs/audio /mnt/e/media/songs/test/outputs/stems /mnt/e/media/songs/test/outputs/youTube Opening E:\media\songs\test
Source Code
#!/usr/bin/env ruby
require 'colorator'
require 'fileutils'
require 'mime/types/full'
# https://github.com/mime-types/ruby-mime-types/
# gem install 'mime-types'
# Creates a new music video (song) subdirectory structure.
# Does not create any files, so this script is idempotent;
# you can accidently call it several times without problems.
#
# Creates this structure:
# ├── daw
# │ ├── live # Ableton Live sets
# │ └── pro_tools # Pro Tools sessions
# ├── dvrArchives # DaVinci Resolve project archives
# ├── inputs # For video editor (DaVinci Resolve) project
# │ ├── images # QR code, etc.
# │ └── videos # A and B rolls
# └── outputs # Renders, mostly by DAWs and video editor
# ├── mp3s # Pro Tools renders
# ├── stems # Zipped audio files
# └── youTube # DaVinci Resolve renders
#
# Sample output:
# $ song_create $songs/test
# The subdirectory structure '$songs/test' already exists. No problem!
# /mnt/e/media/songs/test/daw/live
# /mnt/e/media/songs/test/daw/pro_tools
# /mnt/e/media/songs/test/dvrArchives
# /mnt/e/media/songs/test/inputs/image
# /mnt/e/media/songs/test/inputs/video
# /mnt/e/media/songs/test/outputs/audio
# /mnt/e/media/songs/test/outputs/stems
# /mnt/e/media/songs/test/outputs/youTube
# Opening E:\media\songs\test
#
class SongStructure
attr_reader :this_song_dir, :song_name
def initialize(song_name)
unless song_name
puts "Error: No song name was provided. Aborting.".red
exit 1
end
@song_name = song_name
@songs_dir = ENV.fetch('songs') # root of all songs
unless @songs_dir
puts "Error: Environment variable 'songs' is not defined. Aborting.".red
exit 2
end
if @songs_dir.empty?
puts "Error: Environment variable 'songs' has no value. Aborting.".red
exit 3
end
unless Dir.exist? @songs_dir
puts "Error: Directory #{@songs_dir} does not exist. Aborting.".red
exit 4
end
@this_song_dir = "#{@songs_dir}/#{@song_name}" # root of the new song's directory
end
def create
if File.exist? @this_song_dir
puts "The subdirectory structure '#{@this_song_dir}' already exists. No problem!".yellow
else
puts "Creating a new song subdirectory structure in '#{@this_song_dir}'".yellow
end
[
'daw/live', 'daw/pro_tools',
'dvrArchives',
'inputs/audio', 'inputs/image', 'inputs/video',
'outputs/audio', 'outputs/stems', 'outputs/youTube',
].each do |dir|
puts " #{@this_song_dir}/#{dir}".yellow
FileUtils.mkdir_p "#{@this_song_dir}/#{dir}"
FileUtils.touch "#{@this_song_dir}/#{dir}/.gitkeep"
end
end
def display_this_song_dir
win_song_dir = `wslpath -w '#{@this_song_dir}'`.chomp
puts "Opening #{win_song_dir}".yellow
Dir.chdir("/mnt/c") do
`cmd.exe /c 'explorer.exe /separate, #{win_song_dir}'`
end
end
# Creates a git repo with the same name as the song, but with the 'song_' prefix added if required
def git_repo(this_song_dir, song_name)
Dir.chdir(this_song_dir) do
if Dir.exist? '.git'
puts "The song in '#{this_song_dir}' already has a git repository".yellow
return
else
`git init`
name = song_name.start_with?('song') ? song_name : "song_#{song_name}"
`gh repo create --private --source=. --remote=origin #{name}`
end
write_git_ignore
write_readme
`commit` # See https://mslinn.com/git/1050-commit.html
end
end
# Moves files into position based on:
# 1) Name
# 2) extension if no mimetype
# 3) mimetype (set by examining extension). The Mimetype gem only looks at the filetype,
# not the contents, so the file need not exist.
def move_files(song_dir)
Dir.chdir(song_dir) do
Dir.glob('*').each do |entry|
next if File.directory? entry
filetype = File.extname(entry)[1..]
mimetype = MIME::Types.type_for entry
media_types = mimetype.map(&:media_type).uniq
media_subtypes = mimetype.map(&:sub_type).uniq
subdirectory = if /README.*/.match?(entry) then next # Ignore this file
elsif /.*zip$/.match?(entry) then 'outputs/stems'
elsif media_types.include?('audio') && filetype != 'mp4'
if media_subtypes.include?('midi')
'midi' # Both an input and an output, so make it a peer of input/ and output/
elsif filetype == 'mp3' # This is probably an audio rendering
'outputs/audio'
elsif filetype.start_with? 'aif' # Might be a sample or a render
'outputs'
else # Sample assumed
'inputs/audio'
end
elsif media_types.include?('image') then 'inputs/image'
elsif media_types.include?('video') then 'inputs/video'
else # rubocop:disable Lint/DuplicateBranch
next # Leave unrecognized files where you find them
end
path = "#{@this_song_dir}/#{subdirectory}"
FileUtils.mkdir_p path
FileUtils.mv entry, "#{path}/#{entry}", verbose: true
end
end
end
# This method is not required any more, but I keeping it just in case
def rename_repo
remote_origin_url = `git config --get remote.origin.url`
repo_name = `basename -s .git #{remote_origin_url}`
return if repo_name.start_with?('song')
repo_names = `gh repo list --json name --jq .[].name`.chomp
renamed_repo = "song_#{@song_name}"
if repo_names.include? renamed_repo
puts "#{renamed_repo} already exists, not modified.".yellow
return
end
puts "Renaming git repo '#{@song_name}' to '#{renamed_repo}'.".yellow
`gh repo rename #{renamed_repo} --yes`
end
# Assumes the file should be written to the current directory
def write_file(name, contents)
if File.exist? name
puts "'#{@this_song_dir}/#{name}' already exists, so it was preserved.".yellow
else
puts "Writing '#{@this_song_dir}/#{name}'".yellow
File.open(name, 'w') do |f|
f << contents
end
end
end
# Assumes the file should be written to the current directory
def write_git_ignore
git_ignore = <<~HEREDOC
*.Identifier
*.tmp
*~
~*
.DS_Store
desktop.ini
WaveCache.wfm
HEREDOC
write_file '.gitignore', git_ignore
end
# Assumes the file should be written to the current directory
def write_readme
write_file 'README.md', <<~HEREDOC
# #{@song_name}
Created #{Time.now.strftime "%Y-%m-%d"}
HEREDOC
end
end
if __FILE__ == $PROGRAM_NAME
structure = SongStructure.new ARGV[0]
structure.create
structure.move_files structure.this_song_dir
structure.git_repo structure.this_song_dir, structure.song_name
structure.display_this_song_dir
end
Create Song Webpage
The following script creates a new web page on this website for a new song. Referring to the production overview image, it creates a new web page with the given name in the right-hand area pertaining to Jekyll.
A QR code is also created for the webpage URL, which begins with https://mslinn.com/songs/.
Installation
-
Install dependencies:
Shell
$ gem install colorator -
Save the code as
song_page_createin a directory on thePATH, such as/usr/.local/ bin/ -
Make
song_page_createexecutable:
Shell$ sudo chmod a+x /usr/local/bin/song_page_create
Example Usage
This script can be called from any directory.
It overwrites any previous .html file of the same name in
the collections/_songs/ subdirectory of the website.
Users should commit their changes before calling this script, just to be sure.
$ song_page_create my_song Wrote /var/sitesUbuntu/www.mslinn.com/collections/_songs/my_song.html
Source Code
#!/usr/bin/env ruby
require 'colorator'
require 'fileutils'
# Creates $msp/collections/_songs/#{song_name}.html from song_template.html in the same directory.
# Overwrites the file if present.
# Creates a QR code image.
#
# TODO: update template contents with qr code and other strings. Right now manual editing is necessary
#
# Sample output:
# $ song_page_create space_truckin
# Creating /var/sitesUbuntu/www.mslinn.com/space_truckin.html
# Opening the new web page in VSCode
#
class SongPageCreate
def initialize(song_name)
unless song_name
puts "Error: No song name was provided. Aborting.".red
exit 1
end
@song_name = song_name
@msp = ENV.fetch('msp') # root of mslinn.com (website)
unless @msp
puts "Error: Environment variable 'msp' is not defined. Aborting.".red
exit 2
end
if @msp.empty?
puts "Error: Environment variable 'songs' has no value. Aborting.".red
exit 3
end
unless Dir.exist? @msp
puts "Error: Directory #{@msp} does not exist. Aborting.".red
exit 4
end
@webpage_dir = "#{@msp}/collections/_songs" # path of the directory containing the web page for the new song
@template_path = "#{@webpage_dir}/song_template.html"
unless File.exist? @template_path
puts "Error: '#{@template_path}' does not exist. Aborting."
exit 1
end
@webpage_name = "#{@webpage_dir}/#{@song_name}.html" # path of the web page for the new song
@qr_image = "#{@webpage_dir}/images/qr_#{@song_name}.png"
@webpage_url = "https://www.mslinn.com/songs/#{@song_name}.html"
end
def create
if File.exist? @webpage_name
puts "The webpage '#{@webpage_name}' already exists. IT WILL BE NUKED AND REPLACED NOW.".yellow
else
puts "Creating a new song webpage in '#{@webpage_name}' from 'template.html' in the same directory.".yellow
end
FileUtils.cp @template_path, @webpage_name
end
def display_dir
webpage_name_win = `wslpath -w '#{@webpage_name}'`.chomp
puts "Opening the directory containing #{webpage_name_win}".yellow
`cmd.exe /c 'explorer.exe /separate, #{webpage_name_win}'`
end
# Overwrites
def qr_code
# yes | sudo apt install qrencode
`qrencode -o #{@qr_image} '#{@webpage_url}'`
end
end
if __FILE__ == $PROGRAM_NAME
spc = SongPageCreate.new(ARGV[0])
spc.create
spc.display_dir
spc.qr_code
end
Song Template
View the rendered song template for new songs, and examine its source code:
---
bpm: 120
history: 2024-11-28
date: 2024-11-28
key: C
description: "___, an original composition by Mike Slinn. All rights reserved."
exclude_from_outline: true
guitar_pro_file:
headerImage:
last_modified_at: 2025-04-09
layout: songs
live_file:
mp3:
musescore:
musicxml:
order: -1
pdf:
png:
pro_tools:
published: true
stems:
title: Song Template
---
<!-- #region about -->
{% capture about %}
<p>
This is the song template.
</p>
{% endcapture %}
<!-- endregion -->
<!-- #region audio -->
{%- comment -%}
{% capture audio %}
<p id="mp3_long">
</p>
{% include audio.html mp3="/songs/mp3s/space_truckin.mp3" %}
{% endcapture %}
{%- endcomment -%}
<!-- endregion -->
<!-- #region music_videos -->
{% comment %}
{% capture music_videos %}
{% include video.html youtube_id='6wMf1AHCJXE' %}
{% endcapture %}
{% endcomment %}
<!-- endregion -->
{% include song.html
about=about
audio=audio
change_log=change_log
competition=competition
how_to_play=how_to_play
learning_videos=learning_videos
lyrics=lyrics
music_videos=music_videos
planned=planned
tools_used=tools_used
%}
Zip Stems
The following script packages audio stems into a zip file. It performs the functionality denoted by the dashed line with the label zip in the production overview image.
Pro Tools generates audio stems with a common prefix. The zip file created by this script is automatically named from the common prefix of all the audio stem files.
Installation
-
Install dependencies:
Shell
$ gem install colorator
$ gem install rubyzip -
Save the code as
song_stemsin a directory on thePATH, such as/usr/.local/ bin/ -
Make
song_stemsexecutable:
Shell$ sudo chmod a+x /usr/local/bin/song_stems
Example Usage
This script can be called from any directory.
$ song_stems $songs/my_song Wrote /mnt/e/media/songs/my_song/outputs/stems/my_song_stems_120_bpm.zip
The following is identical to the above:
$ song_stems 'E:\media\songs\one_year_older\outputs\stems' Wrote /mnt/e/media/songs/my_song/outputs/stems/my_song_stems_120_bpm.zip
Source Code
#!/usr/bin/env ruby
require 'colorator'
require 'find'
require 'zip'
# gem install rubyzip
# gem 'rubyzip'
# Zips audio files in songs\your_song\outputs\stems into
# $msp/collections/_songs/stems/ and deletes the original files
#
# If this program is run from either of these song directories:
# /mnt/e/media/songs/one_year_older/
# /mnt/e/media/songs/one_year_older/outputs/stems/
# then the defaults will overwrite any zip file in
# the corresponding www.mslinn.com directory
# U:\var\sitesUbuntu\www.mslinn.com\collections\_songs\stems
#
# In other words, this invocation:
# $ cd $media/songs/one_year_older
# $ song_stems
# are the same as:
# $ song_stems E:/media/songs/one_year_older
# $ song_stems E:/media/songs/one_year_older U:/var/sitesUbuntu/www.mslinn.com/collections/_songs/stems
# $ song_stems $media/songs/one_year_older
# $ song_stems $media/songs/one_year_older $msp/collections/_songs/stems
#
# @param src [String] Can be either a Windows path or a WSL path
# @param dest [String] Defaults to common stems directory for all songs in mslinn.com
# Will be overwritten if it already exists.
class SongStems
def initialize(src = nil, dest = nil)
@src = src.nil? ? Dir.pwd : expand_env(src)
unless File.exist? @src # Did the user provide a WSL path?
# TODO: wslpath fails if @src does not exist; need to handle this
@src = `wslpath '#{@src}'`.chomp # Try again with a Windows path
unless File.exist? @src
puts "Error: directory '#{@src}' does not exist.".red
exit 1
end
end
@src += '/outputs/stems' if File.exist?("#{@src}/outputs/stems")
@dest = if dest.nil? || dest.empty?
"/var/sitesUbuntu/www.mslinn.com/collections/_songs/stems"
else
dest = expand_env dest
dest.exist? ? dest : `wslpath '#{dest}'`.chomp
end
unless File.exist? @dest
puts "Error: directory #{@dest} does not exist.".red
exit 2
end
@input_filenames =
Dir
.glob("#{@src}/*")
.select { |f| File.file?(f) && !f.end_with?('.zip') }
.map { |f| File.basename f }
if @input_filenames.empty?
puts "There are no audio stems in #{@src}, so this program has nothing to do.".red
exit
end
zipname = common_prefix(@input_filenames)
.gsub('_stem', '_stems')
.tr(' ', '_')
.delete_suffix('_')
@zip_path = "#{@dest}/#{zipname}.zip"
end
def expand_env(str)
str.gsub(/\$([a-zA-Z_][a-zA-Z0-9_]*)|\${\g<1>}|%\g<1>%/) do
ENV.fetch(Regexp.last_match(1), nil)
end
end
def make
FileUtils.rm_f(@zip_path)
Zip::File.open(@zip_path, create: true) do |zipfile|
::Zip.sort_entries = true
@input_filenames.each do |filename|
zipfile.add(filename, File.join(@src, filename))
end
end
puts "Wrote #{@zip_path}".green
end
def delete_originals
@input_filenames.each { |f| File.delete "#{@src}/#{f}" }
end
def common_prefix(strings)
return '' if strings.empty?
result = 0
(0...strings.first.length).each do |k|
all_matched = true
character = strings.first[k]
strings.each { |str| all_matched &= (character == str[k]) }
break unless all_matched
result += 1
end
strings.first.slice(0, result)
end
end
if __FILE__ == $PROGRAM_NAME
stems = SongStems.new(ARGV[0])
stems.make
stems.delete_originals
end
Linked Mp3s and Images
I wrote about cross-file system linking options in NTFS/ext4 Compatible Aliases.
The following script performs the functionality denoted by the solid line with the label symlink in the production overview image. Step by step:
- Automatically categories any media file passed to it.
- Categorization is done on the basis of file type.
- Files can be accepted with syntax compatible with Bash, or using NTFS directory and file naming conventions.
- Incoming files are linked to their proper place.
Example Usage
$ cd $one_year_older $ song_link outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3 Wrote /var/sitesUbuntu/www.mslinn.com/songs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3
$ song_link $one_year_older/outputs/mp3s/One\ Year\ Older_55sec_136_bpm_2024-11-26.mp3 Writing /var/sitesUbuntu/www.mslinn.com/collections/_songs/mp3s/One Year Older_55sec_136_bpm_2024-11-26.mp3
Source Code
#!/usr/bin/env ruby
require 'clipboard'
require 'colorator'
# If this program is run from either of these song directories:
# $songs/one_year_older/
# $songs/one_year_older/outputs/mp3s/
# then by default any pre-exising media file in
# the proper subdirectory of $msp/collections/_songs/
#
# The following is true for two equivalent values of the environment variable called songs:
# export songs=/mnt/c/media/songs
# export songs='C:\media\songs'
# This invocation:
# $ cd $songs/one_year_older
# $ song_link outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3
# Performs the same action as all of the following:
# $ song_link $songs/one_year_older/outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3
# $ song_link $songs/one_year_older/outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3 $msp/collections/_songs/mp3s
# $ song_link C:/media/songs/one_year_older/outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3
# $ song_link C:/media/songs/one_year_older/outputs/mp3s/One_Year_Older_136_bpm_2024-11-02.mp3 U:/var/sitesUbuntu/www.mslinn.com/collections/_songs/mp3s
#
# @param src [String] Can be either a Windows path or a WSL path; relative or absolute
# @param dest [String] Defaults to common mp3s directory for all songs in mslinn.com
# Will be overwritten if it already exists.
class SongLinker
def initialize(src = nil, dest = nil)
@msp = compute_msp
@src = compute_src src
@src_name = File.basename @src
@song_name = compute_song_name @src
@dest_dir = compute_dest dest
@dest_path = "#{@dest_dir}/#{@src_name}"
end
def compute_dest(dest)
dest = expand_env(dest)
dest_www = if dest.nil? || dest.empty?
subdir = compute_subdir @src_name
"#{@wsl_vol}#{@msp}/collections/_songs/#{subdir}"
else
win_exist?(dest) ? dest : `wslpath -m '#{dest}'`.chomp
end
return dest_www if Dir.exist? dest_www
if File.exist? dest_www
puts "Error: Destination '#{dest_www}' is a file, not a directory. Aborting.".red
exit 1
end
puts "Error: Windows directory #{@dest_www} does not exist.".red
exit 2
end
def compute_msp
msp = ENV.fetch 'msp'
if msp.nil?
puts "Error: Environment variable msp is undefined".red
exit 3
end
return msp if Dir.exist? msp
if File.exist? msp
puts "Error: Environment variable msp points to a file, not a directory: '#{msp}'".red
else
puts "Error: Environment variable msp points to a directory that does not exist: '#{msp}'".red
end
exit 4
end
def compute_song_name(src)
result = src
.delete_prefix(expand_env("$songs/"))
.split('/')
.first
containing_dir = expand_env "$songs/#{result}"
unless File.exist? containing_dir
puts "Error: Song directory '#{containing_dir}' does not exist".red
exit 5
end
result
end
def compute_src(src)
src = Dir.pwd if src.nil?
src = File.realpath expand_env src
if src.empty?
puts "Error: src file to copy has no value. Aborting.".red
exit 6
end
unless File.exist? src # Did the user provide a WSL path?
# TODO: wslpath fails if src file to copy does not exist; need to handle this
src_tx = `wslpath '#{src}'`.chomp # Try again with a Windows path
unless File.exist? src_tx
puts "Error: file to copy '#{src}' does not exist.".red
exit 7
end
return File.realpath src_tx
end
File.realpath src
end
def compute_subdir(src_name)
case File.extname(src_name).delete_prefix('.')
when 'gp'
'guitar_pro'
when 'gif', 'jpg', 'jfif', 'png', 'webp'
'images'
when 'mp3', 'aiff'
'mp3s'
when 'mccz'
'musescore'
when 'xml'
'musicxml'
when 'pdf'
'pdfs'
when 'zip'
'stems'
end
end
# Does not work
def display_dir
win_home_dos = `cmd.exe /c "echo %systemdrive%%homepath%" 2> /dev/null`.chomp
win_home_linux = `wslpath -au '#{win_home_dos}'`.chomp
Dir.chdir win_home_linux do
@wsl_vol = wsl_volume_name
win_dir = unc_to_win(@dest_path)
puts "Opening #{win_dir}".yellow
`cmd.exe /c 'explorer.exe /separate, #{win_dir}'`
end
end
def expand_env(str)
return nil unless str
str.gsub(/\$([a-zA-Z_][a-zA-Z0-9_]*)|\${\g<1>}|%\g<1>%/) do
ENV.fetch(Regexp.last_match(1), nil)
end
end
def link
if File.exist? @dest_path
puts "Overwriting #{@dest_path}".green
File.delete @dest_path
else
puts "Writing #{@dest_path}".green
end
File.symlink @src, @dest_path
# Clipboard.copy(@dest_path)
end
def unc_to_win(path)
return path.delete_prefix(@wsl_vol) if path.start_with? @wsl_vol
return path.delete_prefix('//wsl$/Ubuntu') if path.start_with? '//wsl$/Ubuntu'
path.delete_prefix('//wsl.localhost/Ubuntu')
end
def wsl_volume_name
line = `cmd.exe /c net.exe use`
.split("\n")
.find { |x| x.include? 'Plan 9 Network Provider' }
if line.nil? || line.empty?
puts 'WSL has no drive letter mapped. Aborting.'
exit 1
end
line.strip.split.first
end
end
if __FILE__ == $PROGRAM_NAME
linker = SongLinker.new(ARGV[0])
linker.link
# linker.display_dir
end
